GF-702汽车插片保险丝座（中号卧式）PCB焊接
东莞市贡福电子有限公司专业制造销售太阳能光伏熔断器、新能源车用保险丝、微型保险丝、叉栓保险丝、汽车保险丝、高压保险丝、贴片保险丝、陶瓷保险丝、汽车保险丝座、汽车熔断器、突跳式温控器、汽车过载保护器，5X20保险丝座，6X30保险丝座，防水保险丝座，小号汽车保险丝座，中号汽车保险丝座，插片保险丝座等。产品通过ul、tuv、ce、ur等认证。客户遍布广东、江苏、东莞、上海等全国各地。
Product introduction
1.material: Contacts--brass, T=0.3mm; Base: PBT UL-94V0
2.terminal finish: Tin plated;
3.Practical: Medium size automobile insert fuse (GFEFUSE ®GF-B series automobile insert fuse medium size)
4.Suitable rated current: 30A@500VAC.
5.Insertion and extraction force: 1Kg Min.
6.Dielectric Strength: Min.AC1000V.
7.Contact Resistance: Max 50mΩ
8.temperature rise: 130° Max.
9.Insluation Resistence At 500V DC: 100mΩ
10.Welding temperature: 260 ℃ 3 seconds
Attention: Product size changes are not notified
